The Holonite Top-down wall covering element is designed to drain water on one side only. This type of element is designed for use on verandas and balconies as the drainage design enables water to be directed away from the veranda/balcony side. In addition to being able to drain water, this wall covering element can be configured so that the water drains in the desired direction.
| Length until 1000 mm | ||||
| Type | Width (B1) | Width (B2) | Max. wall thickness | Rebate (S) |
| TD 170 | 170 | 140 | 130 | 30 |
| TD 260 | 260 | 230 | 220 | 30 |
| TD 300 | 300 | 270 | 260 | 30 |
| TD 340 | 340 | 310 | 300 | 30 |
| TD 360 | 360 | 330 | 320 | 30 |
| TD 380 | 380 | 350 | 340 | 30 |
| TD 400 | 400 | 370 | 360 | 30 |
| TD 460 | 460 | 430 | 420 | 30 |
All dimensions are in millimeters.
| Length until 1500 mm | ||||
| Type | Width (B1) | Width (B2) | Max. wall thickness | Rebate (S) |
| TD 170 | 170 | 140 | 130 | 30 |
| TD 260 | 260 | 230 | 220 | 30 |
| TD 300 | 300 | 270 | 260 | 30 |
| TD 340 | 340 | 310 | 300 | 30 |
| TD 360 | 360 | 330 | 320 | 30 |
| TD 380 | 380 | 350 | 340 | 30 |
| TD 400 | 400 | 370 | 360 | 30 |
| TD 460 | 460 | 430 | 420 | 30 |
All dimensions are in millimeters.
| End piece until 500 mm | ||||
| Type | Width (B1) | Width (B2) | Max. wall thickness | Rebate (S) |
| TD 170 | 170 | 140 | 130 | 30 |
| TD 260 | 260 | 230 | 220 | 30 |
| TD 300 | 300 | 270 | 260 | 30 |
| TD 340 | 340 | 310 | 300 | 30 |
| TD 360 | 360 | 330 | 320 | 30 |
| TD 380 | 380 | 350 | 340 | 30 |
| TD 400 | 400 | 370 | 360 | 30 |
| TD 460 | 460 | 430 | 420 | 30 |
All dimensions are in millimeters.
