Base plinths Uninsulated base plinths

Product information Uninsulated base plinths

Base plinths are the ideal technical and aesthetic finish for the foot of a building, e.g. when applying exterior façade insulation. Insulated base plinths are available in standard lengths of one metre and in various standard heights. As it is simple to process the 20-mm-thick panels, shims can easily be cut to size and applied accordingly. The plinths do not have to be sealed thanks to the precise cut-off point. Insulated base plinths have EPS or XPS insulation. If technically possible, other insulation materials can be discussed and subsequently utilised. Holonite can provide all requisite information about how to treat and process the base plinths correctly.

Dimensions

To CAD & Specification Service
Width (W1) Height (H1) Length (L)
20 200 997
20 300 997
20 400 997
20 500 997
20 600 997



All dimensions are in millimeters.

Colours The product is available for color and textures

Basic colors
  • 6Light grey
  • 7Anthracite
  • 20Dark grey
  • 1White
  • 5Earth brown
  • 23Brown grey
  • 11Sand yellow
Natural
  • 16Natural sand yellow
  • 21Natural dark grey
  • 14Natural red brown
  • 15Natural black
  • 25Natural brown grey
Texture
  • 12Sabbia
  • 10Terra
  • 13Savona
  • 22Misto
  • 24Marrone
  • 8Tarente

Download Documentation

Do you need guidelines for the correct handling and processing/assembly of our products? Then take a look at our downloads.
